Galvanized Barbed Wire Mesh Plastic

Overview

Basic Info.

Finish	Hot Dipped Galvanized
Razor Barbed Type	Barbed
Wire Gauge	15-1/2x15-1/2 BWG
Barbed Distance	3"
Barb Length	22mm
Coil Outside Diameter	600mm
Color	All
Trademark	Dengfeng
Origin	China
Production Capacity	50000meters

Product Description

BARBED WIRE Material: high quality low carbon steel wire,stainless steel wire ,medium carbon steel wire(galvanized,plastic coated, plastic sprayed)Type: double twisted barbed wire ,general barbed wire,single strand barbed wire.PVC barbed wire,stoving varnish barbed wire. Performance and characteristic:by twisting and weaving,firm and beautiful.Product size

Barbed Wire
Material	High quality low carbon steel wire, iron wire, etc.
Category	1.Hot dipped galvanized2.Electric galvanized 3.PVC coated
Weving and Characteristic	Twist weaving,firm and beautiful,corrosion-resisting and oxidation-resisting.
Using	Used as barrier for lawn, railways, expressways,etc
Specification	2 strands,4 points.Barbs' distance 3-6 inches

Gauge of	Approximate Length per Kilo in Meter
Strand and Barb in B.W.G.	Barbs Spacing 3"	Barbs Spacing 4"	Barbs Spacing 5"	Barbs Spacing 6"
12x12	6.0617	6.759	7.27	7.6376
12x14	7.3335	7.9051	8.3015	8.5741
12-1/2x12-1/2	6.9223	7.719	8.3022	8.7221
12-1/2x14	8.1096	8.814	9.2242	9.562
13x13	7.9808	8.899	9.5721	10.0553
13x14	8.8448	9.6899	10.2923	10.7146
13-1/2x14	9.6079	10.6134	11.4705	11.8553
14x14	10.4569	11.659	12.5423	13.1752
14-1/2x14-1/2	11.9875	13.3671	14.3781	15.1034
15x15	13.8927	15.4942	16.6666	17.507
15-1/2x15-1/2	15.3491	17.1144	18.406	19.3386
Barbed distance :7.5-15/cm Barbed length:1.5-3/cm

Detailed Photos

Strand structure of barbed wire
Barbed wire can be divided into single strand barbed wire and double strand barbed wire.
* Single strand barbed wire. It has the simplest structure, which contains single strand and barbs. Compared with the double strand barbed wires, it is much more economical and lighter weight. It is suitable for the common applications. But it is easy to destroy and cut, so it is not suitable for heavy duty applications.
* Double strand barbed wire. It is formed with two strand wires (line wires). The barbs are twisted between of the two wires and fastened onto the line wire. The double strand barbed wire can supply higher tensile strength to prevent cutting or destroying. It is suitable for the heavy duty applications, such as prisons, other places.

Barb structure of barbed wire
Barbs are very important for the barbed wire. The strong barbs with sharp points can resist bending. It can frighten and de fend thieves and intruders. They can also contain your animals and livestock safely in your farm or ranching. The barb can be single or double wires for different applications.
* Single barb. Also known as 2-point barbed wire. It is contains single barb wire twisted on the line wire. The single barb wires is used in the common applications. Or if your farms or pens has enough space for rearing animal or livestock, you can choose the single barb (2-point) barbed wire.
* Double barbs. It is also called 4-point barbed wire. Use two barb wires twisted together onto the line wire. It can supply
greater hurt factor for your sites or ranching. It is widely used in the heavy duty applications. Or if your farms or ranches has a herd pressure, you can choose the 4-point barbed wire.Packaging & Shipping

Package of barbed wire
The barbed wire is commonly supplied in rolls. And there are so many barbs on the roll surface. For convenient loading, handling and transporting, we are equipped different handles for your choice. Additional, it is very safe for manual operation and will not hurt people when using it.
* Steel wire roller and steel wire handle.
* Steel wire roller and plastic handle.
* Steel wire roller and wooden handle.
* Wooden roller and rope handle.
Inside waterproof paper ,outside woven bag for barbed wire,Or according to your requirements
Application

Barbed wire can be widely used as accessories for woven wires fences to form a fencing system or security system. It is called barbed wire fences or barbed obstacles when it is used simply by itself along the wall or the building to give a kind of protection. Barbed wire is also written as barbed tape as it is always used in a line to form a kind of tape!

Our Advantages

Anping County Dengfeng Wire Mesh PRODUCTS CO., LTD which was born in 2008, located in Anping county, He Bei Province, covers an area of more than 66000 square meters, the annual output get to 5 million square meters, and the daily output of fence is 10 kilometers. Our company is a large-scale professional fence manufacturing enterprises in producing (from raw material--straining--welding--PVC painted/coated--products),installing and services ability.

FAQ

1. who are we?
We are based in Hebei, China, start from 2008,sell to Northern Europe(28.00%),Western Europe(28.00%),Africa(26.00%),Central America(26.00%),Southern Europe(24.00%),Eastern Europe(24.00%),Eastern Asia(24.00%),Domestic Market(23.00%),Mid East(23.00%),South Asia(22.00%),Southeast Asia(21.00%),Oceania(21.00%),South America(21.00%),North America(20.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Field Fence,Perforated Metal Mesh,Stainless Steel Wire Mesh,Gas Liquid Filter Wire Mesh,Wire Mesh Deep Processing Products
4. why should you buy from us not from other suppliers?
We are a professional manufacturer with 14 years of experience.
Strict monitoring of the production process to avoiding quality problem
We have advanced technology and equipment.
We have a strong after-sales team
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES;
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
